| Reference No. | Part No. | Description | Reference No. | Part No. | Description |
|---|---|---|---|---|---|
| 1 | 002003 | N Tip 1.2 mm | 5 ~ 7 | 3002042 | TK-508RX Torch Body |
| 002017 | N Tip 1.4 mm | 1 ~ 7 | 3002041 | TK-508RX Torch Body Assy | |
| 002004 | N Tip 1.6 mm | 8 | 3002014 | TK-508RX Clamp Block Cover | |
| 2 | 001001 | N Nozzle 19 mm/500 A | 9 | 3002013 | TK-508RX Clamp Block |
| 3 | 003001 | N Orifice L | 10 | 3002012 | TK-508RX Clamp Body |
| 4 | 004001 | N Insulator L | 11 | 016052 | TK-508RR Insulation Collar |
| 5 | 016403 | TK-508RR Tip Body | 8 ~ 12 | 3002011 | TK-508RX Clamp Body Assy |
| 6+7 | 3002043 | TK-508RX Torch Body (w/o Tip Body) | 12 | 016053 | TK-508RR Inner Tube |
| 7 | Y0000FP10 | O Ring F-P10 | 1 ~ 12 | 3002040 | TK-508RX Torch Assy |
